Section 9 - Specifications
9-5
3126018
Dimensions
Overall Height..................................................................................101 in (2565 mm)
Overall Width
G10-55A ....................................................................................101 in (2565 mm)
G12-55A ....................................................................................102 in (2591 mm)
Cab Width............................................................................................37 in (940 mm)
Track Width ....................................................................................85.4 in (2169 mm)
Wheelbase ......................................................................................144 in (3658 mm)
Length at Front Wheels ...................................................................201 in (5105 mm)
Overall Length (less Forks) .............................................................254 in (6452 mm)
Ground Clearance
G10-55A ........................................................................................18 in (457 mm)
G12-55A ........................................................................................19 in (482 mm)
Turning Radius Over Tires ............................................................. 156 in (3962 mm)
Turning Radius at Forks ..................................................................168 in (4267 mm)
Maximum Gross Vehicle Weight (no attachment)
Before S/N 0160039451 excluding 0160039394 &
0160039397......................................................................... 37,790 lb (17.141 kg)
S/N 0160039451 & After including 0160039394 &
0160039397......................................................................... 38,060 lb (17.264 kg)
Maximum Front Axle Weight (no attachment)
(boom level and fully retracted)
Before S/N 0160039451 excluding 0160039394 &
0160039397............................................................................ 19,726 lb (8948 kg)
S/N 0160039451 & After including 0160039394 &
0160039397............................................................................ 19,867 lb (9012 kg)
Maximum Rear Axle Weight (no attachment)
(boom level and fully retracted)
Before S/N 0160039451 excluding 0160039394 &
0160039397............................................................................ 18,064 lb (8194 kg)
S/N 0160039451 & After including 0160039394 &
0160039397............................................................................ 18,193 lb (8252 kg)
