SECTION 2 - TURNTABLE
84 800S/860SJ 3121632
ITEM PART NUMBER QTY DESCRIPTION REV
114 7024441 1 Gauge, Sight
117 7024443 1 Neck, Fill
118 83304174 6 Nut 1/4in-20NC
119 4751600 2 Flatwasher 3/8in Regular
121 83304173 6 Flatwasher 1/4in
122 83304170 2 Bolt 3/8in-16NC x 1-1/2in
123 83304172 6 Stud 1/4in-20NC
124 7024445 1 Screen
127 7024444 1 Breather/Fill Cap
128 7024446 1 Plug, Magnetic
129 Not Available 22
in/55cm
Trim
Ref FUEL TANK COMPONENTS
1001160567 Ref Diesel Machines A
1001108579 Ref Diesel Machines (Hostile Environment Machines Only) E
1001091563 Ref GM Machines B
201 Ref Cap Options:
201A Not Available Standard Non-Locking (P/N 1001160567Tank)
201A Not Available Standard Non-Locking (P/N 1001108579 Tank)
201A 70001103 1 Standard Non-Locking (P/N 1001091563 Tank)
201B 1120487 1 Optional Lockable (Diesel Machines Only) (Note: Lock Not
Included)
202 Ref Tube, Fuel Pick-up Options:
202 Not Available Tube for p/n 1001160567 Tank
202 Not Available Tube for p/n 1001108579 Tank
202 Not Available Tube p/n 1001091563 Tank
203 Not Available 1 Plug
