SECTION 1 - FRAME
3121632
800S/860SJ
29
FIGURE 1-6. FRAME VALVES AND SHIELDS INSTALLATIONS
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001157015
Ref
DRIVE VALVES INSTALLATION - 2WD
A
2
0641542
2
Bolt 5/16in-18NC x 5-1/4in
11
3311505
2
Locknut 5/16in-18NC
12
1001099870
1
Flow Divider Valve Assembly
A
12A
7023933
1
Cartridge, Flow Divider
12A
7021625
1
Seal Kit - 7023933 Cartridge
12A
70000781
1
Lockdown Kit
12B
7022397
2
Cartridge, Check
12B
7022399
2
Seal Kit - 7022397 Cartridge
12C
70002390
2
Cartridge, Check
12C
7022399
2
Seal Kit - 70002390 Cartridge
12D
7024881
1
Piston, Pilot
12E
7017406
1
Plug
12F
7024844
1
Plug
12F
7017492
1
Orifice
13
4711500
4
Flatwasher 5/16in Thin
1001157016
Ref
DRIVE VALVES INSTALLATION - 4WD
A
102
0641560
3
Bolt 5/16in-18NC x 7-1/2in
110
3311505
3
Locknut 5/16in-18NC
111
4641303
1
Flow Divider Valve Assembly
111A
7023933
1
Cartridge, Flow Divider
111A
7021625
1
Seal Kit - 7023933 Cartridge
111B
7022397
6
Cartridge, Check
111B
7022399
6
Seal Kit - 7022397 Cartridge
111C
7021639
2
Cartridge, Check Valves
111C
2900756
2
Seal Kit - 7022398 Cartridge
111D
7024881
1
Piston, Pilot
111E
7023917
2
Cartridge, Flow Divider
111E
7021625
2
Seal Kit - 7023917 Cartridge
111F
70003935
2
Orifice
111G
70003936
1
Orifice
112
4711500
6
Flatwasher 5/16in Thin
1001158203
Ref
FRAME SHIELDS INSTALLATIONS (2WS)
D
1001158204
Ref
FRAME SHIELDS INSTALLATIONS (4WS)
C
201
0100011
AR
Compound, Locking
202
0641606
2
Bolt, 3/8in - 16NC x 3/4in
203
4751600
2
Flatwasher 3/8in Regular
204
1001158187
1
Cover
205
4280296
27
in/68cm
Trim
206
1001158188
1
Cover (2WS Only)
209
8580420
2
Nut, Well (2WS Only)
210
0641410
2
Bolt 1/4in-20NC x 1-1/4in (2WS Only)
211
4751400
2
Flatwasher 1/4in Regular (2WS Only)
