SECTION 2 - TURNTABLE
3121632
800S/860SJ
41
FIGURE 2-3. MAIN CONTROL VALVE ASSEMBLY (SN 0300190437 to Present)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001154598
Ref
MAIN CONTROL VALVE ASSEMBLY (SN 0300190437 to
Present)
B
1
70004570
1
Cartridge, Solenoid Valve (Main Dump)
1
70004571
1
Seal Kit - 70004570 Valve
2
7023925
1
Cartridge, Solenoid Valve (Steer)
2
7012903
1
Seal Kit - 7023925 Valve
3
7017452
1
Cartridge, Solenoid Valve (Tele)
3
7017402
1
Seal Kit - 7017452 Valve
4
7021612
1
Cartridge, Solenoid Valve (Lift)
4
7012907
1
Seal Kit - 7021612 Valve
5
70003022
1
Cartridge, Solenoid Valve (Swing)
5
7012903
1
Seal Kit - 70003022 Valve
6
70004572
1
Cartridge, Solenoid Valve (Tele)
6
70004573
1
Seal Kit - 70004572 Valve
7
70004574
1
Cartridge, Valve
7
70004575
1
Seal Kit - 70004574 Valve
8
70004576
1
Cartridge, Valve
8
70004577
1
Seal Kit - 70004576 Valve
9
10837580
1
Cartridge, Valve
9
7010543
1
Seal Kit - 10837580 Valve
10
7017422
1
Cartridge, Valve
10
7012998
1
Seal Kit - 7017422 Valve
11
70004578
1
Cartridge, Valve
11
7021653
1
Seal Kit - 70004578 Valve
12
70003788
5
Coil
13
70002386
3
Coil
14
70003789
1
Coil
15
70004579
1
Cartridge, Valve
15
70004580
1
Seal Kit - 70004579 Valve
16
70004581
1
Cartridge, Valve
16
70004571
1
Seal Kit - 70004581 Valve
17
7023985
1
Cartridge, Valve
17
7017496
1
Seal Kit - 7023985 Valve
