SECTION 2 - TURNTABLE
106
800S/860SJ
3121632
FIGURE 2-17. HOODS (STEEL) AND LIFTING PLATE INSTALLATIONS
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
NOTE: REPLACEMENT DECALS MUST BE PURCHASED
SEPARATELY - SEE DECALS SECTION.
Ref
HOODS INSTALLATIONS
1001157416
Ref
Standard Machines
C
1001157753
Ref
Hostile Environment Machines
C
1
0100011
AR
Compound, Locking
2
0100081
AR
Adhesive
3
1001161711
1
Mount
4
0641406
4
Bolt 1/4in-20NC x 3/4in
6
0641608
12
Bolt 3/8in-16NC x 7/8in
8
0641613
3
Bolt 3/8in-16NC x 1-5/8in
9
0641616
2
Bolt 3/8in-16NC x 2in
10
0811812
8
Bolt 1/2in-13NC x 1-1/2in
11
0902673
1
Bracket
12
0940049
2
Stopper, Hood
13
1120601
1
Plug
14
2080040
4
Fastener, Huck
15
2080072
4
Retainer
16
2940045
2
Latch, Paddle
17
3300364
5
Nut, Tinnerman
18
3311405
4
Locknut 1/4in-20NC
19
3311501
2
Nut 5/16in-18NC
21
3311601
1
Nut 3/8in-16NC
22
3311605
22
Locknut 3/8in-16NC
23
3520030
1
Plug, Hole
24
3900210
5
Screw, Button Head 5/16in-18 x 3/4in
25
3900316
17
Screw, Button Head 3/8in-16NC x 1in
26
3960389
54 in/1.4m
Seal
27
4061032
1
Shield
28
4160194
4
Spring, Gas
29
4240018
3
Tie-Strap (Not Shown)
31
4751400
4
Flatwasher 1/4in Regular
32
4751500
7
Flatwasher 5/16in Regular
33
4751600
50
Flatwasher 3/8in Regular
34
1001110166
61
in/1.6mm
Seal
35
1001113047
84
in/2.14m
Seal
36
1001116280
1
Bracket, Hood
37
1001116322
1
Door
38
Ref
Door Options:
38
1001116344
1
Standard Machines
38
1001125501
1
Hostile Environment Machines (Not Shown)
39
1001117249
1
Plate, Seal
40
1001116358
1
Bracket
41
Ref
Hood Options:
41
1001116558
1
Standard Machines
41
1001125502
1
Hostile Environment Machines (Not Shown)
42
1001116620
1
Hood
43
1001117027
1
Bracket
