SECTION 7 - ELECTRICAL
3121632 800S/860SJ 231
ITEM PART NUMBER QTY DESCRIPTION REV
714B 4711400 4 Flatwasher 1/4in (Narrow)
714C Ref Kit, Box and Breaker (Required on CE Spec Installations):
714C 1001109654 AR Machines without Powermite Generator Control Box A
714C 1001109648 AR Machines with Powermite Generator Control Box A
714C Ref Circuit Breaker
714C 1001109477 1 Breaker 10A
714C 1001109475 1 Breaker 16A
714C 1001109482 1 Breaker 30mA
714C 0861880 1 Breaker Box
714C 4460956 1 Terminal, Block End Barrier
714C 1060908 6 ft/1.8m Cable, Extension
714C 4460957 1 Terminal Block
714D Ref Connector, Strain Relief Options:
714D 1001101191 1 Top
714D 1001097150 1 Bottom
714D 0641406 2 Bolt 1/4in-20NC x 3/4in
714D 3311405 2 Locknut 1/4in-20NC
714D 4711400 4 Flatwasher 1/4in (Narrow)
714E 1060908 12 ft/3.6m Cable, Electrical 12/3
714F 4460709 1 Plug, Male
714G 4460710 1 Connector, Female
715 1001094509 1 Generator Hourmeter Harness A
Ref TOOLS
801 7002821 1 Crimper (For Wire to Pin/Socket Connections) (Not Shown)
802 7002823 1 Extractor (For Removal of Pin/Socket from Connectors) (Not
Shown)
803 4460467 1 Extractor, Pin (Blue 16-18 Gauge) (For Removal of Pin/Socket
from Connectors) (Not Shown)
804 4460510 1 Extractor, Pin (Yellow 12-14 Gauge) (For Removal of Pin/Socket
from Connectors) (Not Shown)
805 7002828 1 Stripper, Wire (Not Shown)
806 2901443 1 Analyzer Kit (Not Shown)
806A 1600244 1 Analyzer
806B 1060633 1 Cable, Analyzer 1-A
806C 4460321 2 Plug, Male
806C 4460226 8 Socket, Female
