Page 43
SECTION 2 - TURNTABLE
3121632
800S/860SJ
43
FIGURE 2-4. TURNTABLE BEARING AND SWING DRIVE INSTALLATION
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001094899
Ref
SWING DRIVE INSTALLATION
B
1
0100019
AR
Compound, Locking
2
0682216
4
Bolt 3/4in-10NC x 2in Grade 8
3
3312002
1
Nut, Jam 3/4in-10NC
4
3900293
1
Bolt, Shoulder
5
3952020
2
Setscrew 5/8in-11NC x 2-1/2in
6
4071009
1
Shim
7
4740057
4
Flatwasher 3/4in Hardened
8
1001101060
1
Swing Motor/Swing Hub Assembly (See SWING MOTOR/HUB
ASSEMBLY for Breakdown)
0271002
Ref
TURNTABLE BEARING INSTALLATION
E
101
0100019
AR
Compound, Locking
102
0440244
1
Bearing, Turntable
103
0682023
24
Bolt 5/8in - 11NC x 2-7/8in Grade 8
104
0682032
24
Bolt 5/8in - 11NC x 4in Grade 8
105
4892000
48
Flatwasher, 5/8in Hardened
0259147
Ref
TURNTABLE LOCK INSTALLATION
B
201
4844958
1
Pin
202
3421565
1
Pin, Snap
203
3760170
2
Ring, Quick Release
204
1260017
9 in/23cm
Chain
1001161076
Ref
REMOTE BEARING LUBE INSTALLATION
A
301
0100011
AR
Compound, Locking
302
1001157058
1
Hose and Fitting Assembly
