SECTION 2 - TURNTABLE
36
800S/860SJ
3121632
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
151
70002998
1
Motor
152
70004266
1
Pump
153
70001020
4
Screw
154
70003612
2
O-Ring
155
70004267
1
O-Ring
1001157261
Ref
MANUAL DESCENT INSTALLATION (OPTIONAL)
A
202
0641420
2
Bolt 1/4in-20NC x 2-1/2in
203
0641507
2
Bolt 5/16in-18NC x 7/8in
206
1380136
2
Clip, Gripper
207
1702901
1
Decal - Manual Descent (Not Shown - Located on hood)
208
1702903
1
Decal - #1
209
1702924
1
Decal - #3
210
1702925
1
Decal - #4
211
1702927
1
Decal - #2
212
1705589
1
Decal - Manual Descent (Not Shown - Located on Hydraulic Tank)
213
2560122
1
Handle
214
2560123
1
Handle, Grip
216
2900062
1
Kit, Valve Mounting
217
3311005
2
Locknut #10-24NC
218
3311405
2
Locknut 1/4in-20NC
219
3311505
4
Locknut 5/16in-18NC
221
3574179
1
Plate, Valve Mounting
222
3911008
2
Screw #10-24NC x 1/2in
225
4640930
1
Manifold, Manual Descent Assembly
225A
Ref
Cartridge, Needle Options:
225A
4640902
4
Cartridge, Needle (was p/n 7012954) (Original Equipment)
225A
7012953
4
Seal, Kit - 7012954 Cartridge
225A
4640902
4
Cartridge, Needle (Service Replacement)
225A
7012953
4
Seal, Kit - 4640902 Cartridge
225B
7012961
4
Knob
225C
Ref
Cartridge, Pump Options:
225C
70004019
1
Cartridge, Pump (was p/n 7012694) (Original Equipment)
225C
7012699
1
Seal, Kit - 7012694 Cartridge
225C
70004019
1
Cartridge, Pump (Service Replacement)
225C
7017496
1
Seal, Kit - 70004019 Cartridge (was p/n 2900756)
227
4641263
1
Valve, Metering
228
4751000
2
Flatwasher #10 Regular
229
4751400
2
Flatwasher 1/4in Regular
230
4751500
6
Flatwasher 5/16in Regular
