SECTION 7 - ELECTRICAL
216 800S/860SJ 3121632
FIGURE 7-2. HARNESS COMPONENTS INSTALLATION
ITEM PART NUMBER QTY DESCRIPTION REV
1001141140 Ref PLATFORM CONSOLE BOX COMPONENTS A
5 Ref Footswitch Components
5A 1060918 7.5
ft/2.3m
Cable, Electrical - 18/3
5A 0100020 AR Sealant
5B 4460071 1 Connector, Strain Relief
5C 4460464 1 Pin, Male
5C 4460226 2 Socket, Female
12 See Note 1 Controller Harness Assembly (Lift and Swing) (Note: Not Available
for Purchase.)
12A 7022819 1 Plug, Male - 8 Position (Natural)
12A 4460871 8 Socket, Female
13 See Note 1 Controller Harness/Circuit Board Assembly (Drive and Steer)
(Note: Not Available for Purchase.)
13A 7022825 1 Plug, Male - 8 Position (Black)
13A 4460871 7 Socket, Female
33 See Note 1 Controller Harness (Speed Control) (Note: Not Available for
Purchase.)
33A 4460224 1 Receptacle, Female - 6 Position
33A 4460226 6 Socket, Female
39 4460428 2 Connector, Strain Relief
40 4460470 1 Nut, Terminal
41 4460471 1 Lockwasher, Terminal
42 4460496 1 Lockwasher, Terminal
43 4460497 1 Nut, Terminal
44 4460708 2 Receptacle - 15 Position
45 4460905 5 Seal, Plug
49 4922666 1 Harness, Analyzer Cable 2-B
49 4460226 4 Socket, Female (Not Shown - Located at J2)
49A 4460761 1 Connector, Female - 4 Position
49A 4460227 4 Pin, Male
52 1001141136 1 Harness, Platform Box (See Items 101-111 for Breakdown)
1001141136 Ref PLATFORM BOX HARNESS ASSEMBLY A
101 4460866 1 Connector - 19 Pin
101 4460929 10 Pin, Male Deutsch 16 Ga
101 4460508 3 Pin, Male Deutsch 12 Ga
102 4460874 1 Connector - 35 Position (Natural)
102 4460871 23 Socket, Female
103 4460876 1 Connector - 35 Position (Blue)
103 4460871 23 Socket, Female
104 4460873 1 Connector - 35 Position (Black)
104 4460871 28 Socket, Female
105 4460879 1 Connector, Male 2 Position
105 4460887 2 Terminal (12 Gauge)
106 4460418 7 Connector, Female - 6 Position
106 4460419 21 Socket, Female
107 4460225 4 Connector - 6 Position
107 4460226 18 Terminal (16 Gauge)
108 4460225 1 Connector - 6 Position
108 4460227 5 Pin, Male
