SECTION 4 - MACHINE OPERATION
4-12 – JLG Lift – 3128792
Retracting The Outriggers
(Reference Figure 4-3. for item numbers)
Either - Press and hold button no. 1 (item 1)
of the remote control.
The 4 outriggers will all retract at the same
time and lower the machine.
or
Operate each outrigger separately by
pressing button 2 (item 2) to select which
outrigger to control (each outrigger is num-
bered 1 thru 4, see decal at each outrigger,
each press of button 2 displays the outrig-
ger selected on the LCD display). Press but-
ton 1 (item 1) to retract or button 7 (item 7)
to set that outrigger.
Note: To cycle back to outrigger auto-retract
mode, press button 2 (item 2) until the LCD
display shows the normal operating icons.
AUTO
1
MANUAL
SELECT
2
