SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE
6-18 – JLG Lift – 3128792
MENUS 4; 5; CANNOT BE ACCESSED
Menu Input
The signals that arrive at the board from the various sensors
mounted on the machine and from the platform/remote con-
trol commands are displayed. The status of the input and the
following selection to scroll the menu appears for each
screen:
1 - PREV - access the previous input
2 - NEXT - access the successive input
9 - ESC - escape from the INPUT menu
LIGHTLIFT SELF-PROPELLED AERIAL PLATFORM - X390AJ
ST1 GND A
Both ON indicate the stabilizer 1 rests on the ground.
ST1 GND B
ST2 GND A
Both ON indicate the stabilizer 2 rests on the ground.
ST2 GND B
ST3 GND A
Both ON indicate the stabilizer 3 rests on the ground.
ST3 GND B
ST4 GND A
Both ON indicate the stabilizer 4 rests on the ground.
ST4 GND B
ST1 OPEN A
Both ON indicate the stabilizer 1 is completely open,
TOTAL AREA.
ST1 OPEN B
ST2 OPEN A Both ON indicate the stabilizer 2 is completely open,
TOTAL AREA
ST2 OPEN B
ST3 OPEN A
Both ON indicate the stabilizer 3 is completely open,
TOTAL AREA
ST3 OPEN B
ST4 OPEN A
Both ON indicate the stabilizer 4 is completely open,
TOTAL AREA
ST4 OPEN B
BYPASAE A
Both ON indicate aerial part safety devices have been
disconnected by the specially provided key.
BYPASAE B
BYPASCB A
Both ON indicate undercarriage part safety devices have
been disconnected by the specially provided key.
BYPASCB B
EM. GRND A
Both ON indicate that emergency stop button isn't
pressed (from ground).
EM. GRND B
FOTO A
Both ON indicate that the photocells are aligned.
FOTO B
EM R.C. GND
Both ON indicate that the remote control button isn't
pressed (from ground).
ST12 CLOSED ON status indicates the stabilizers 1-2 are completely up
and pressurized.
ST34 CLOSED ON status indicates the stabilizers 3-4 are completely up
and pressurized.
TEMP ALRM A Both ON indicate the external temperature probe is acti-
vated (only Russian version).
TEMP ALRM B
