SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE

3128792

– JLG Lift –

6-3

Capacities

Engine Data

Gross machine weight (platform empty):

3,682 lb (1,670 kg)

Table 6-4. Capacities

Model

X390AJ

Hydraulic Tank

6.6 gal (25 L)

Fuel Tank

Gasoline:

Diesel:

1.4 gal (5 L)
1.3 gal (5 L)

Engine Oil

Gasoline:

Diesel:

0.3 gal (1.1 L)
0.4 gal (1.5 L)

Table 6-3. Chassis Data

Model

X390AJ

Table 6-5. Honda iGX390 Specifications

Model

X390AJ

Type

Air cooled

Number of cylinders

Displacement

23.7 cu. in. (389 cm

)

Output

13 hp (9.7 kW)

High engine speed

3000 RPM

Table 6-6. Hatz 1B30 Specifications

Model

X390AJ

Type

Air cooled

Number of cylinders

Displacement

21.2 cu. in. (347 cm

)

Output

7 hp (5.22 kW)

High engine speed

3000 RPM
