SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE
6-2 – JLG Lift – 3128792
6.2 OPERATING SPECIFICATIONS
Dimensional Data
Chassis
Table 6-1. Operating Specifications
Model X390AJ
Maximum work load (capacity)
Unrestricted:
Restricted:
300 lbs (136 kg)
440 lbs (200 kg)
Max. Vertical Platform Height
Unrestricted:
Restricted:
45.6 ft (13,90 m)
40.2 ft (12,25 m)
Max. Horizontal Platform Reach
Unrestricted:
Restricted:
22.2 ft (6,76 m)
17.8 ft (5,42 m)
Table 6-2. Dimensional Data
Model X390AJ
Overall Width (with platform removed) 31 in (0.77 m)
Outriggers Deployed Width 9 ft 7 in x 9 ft 5 in
(2.9 m x 2.8 m)
Stowed Height 6 ft 10 in (2.07 m)
Stowed Length 13 ft (3.98 m)
Approach angle with Jib lowered: 20°
Departure angle 20°
Table 6-3. Chassis Data
Model X390AJ
Maximum Travel Grade w/ boom in stowed
position (gradeability) 20° (36%)
Maximum Travel Side Slope w/ boom in
stowed position 10°
Turning radius 0°
Maximum ground pressure - track (psi) 7.25 psi (0.51 kg/cm 2 )
Maximum ground pressure per outrigger 24.66 psi (1,73 kg/cm 2 )
Maximum outrigger pad load 2,698 lb (1,200 kg)
Outrigger pad diameter 11.8 in (300 mm)
Max drive speed 0.87 mph (1.4 km/hr)
Max hydraulic system pressure 2393 psi (165 bar)
Maximum wind speed 28 mph (12.5m/s)
Maximum manual force 90 lb (400 N)
Electrical system voltage 12V
