SECTION 6 - JLG CONTROL SYSTEM
6-32 – JLG Lift – 3121607
CABLE SWITCH:
16* 0
1 NO: No broken cable switch installed.
YES: Broken cable switch installed. 0
* Certain market selections will alter default setting.
LOAD SYSTEM:
17* 0
1
2
3
4
NO: No load sensor installed.
WARN ONLY: Functions in creep, overload lamp lit, platform alarm beeps (5
sec ON, 2 sec OFF).
CUTOUT PLATFORM: All functions cutout, overload lamp lit, platform alarm
beeps (5 sec ON, 2 sec OFF).
CUTOUT ALL: All functions cutout, flash overload light (500mS on, 500mS
off ), platform alarm beeps (5 sec ON, 2 sec OFF).
SPECIAL 1: Functions in creep, overload lamp lit, disables main telescope out
& main lift up, platform alarm beeps (5 sec ON, 2 sec OFF).
0
* Only visible under certain market selections.
* Certain market selections will limit load system options or alter default setting.
LOAD SENSOR:
18* 0
1
1 ON ROTATOR: Use the on-board load sensor for all models except those
which use the Leveling Platform Module.
4 UNDER PLATFORM: Use the EIM for load sensing.
1
* Only visible under certain market selections.
* Certain market selections will limit load system options or alter default setting.
FUNCTION CUT-
OUT:
19* 0
1
2
3 NO: No drive cutout.
BOOM CUTOUT: Boom function cutout while driving above elevation.
DRIVE CUTOUT: Drive cutout above elevation.
DRIVE CUT E&T: Drive cutout above elevation and tilted. 0
* Only visible under certain market selections.
* Certain market selections will limit load system options or alter default setting.
GROUND ALARM:
20* 0
1
2
3 NO: No ground alarm installed.
DRIVE: Travel alarm sounds when the drive function is active (Option).
DESCENT: Descent alarm sounds when lift down is active (Option).
MOTION: Motion alarm sounds when any function is active (Option). 3
* Certain market selections will alter default setting.
Table 6-5. Machine Configuration Programming Information
Configuration Digit Number Description
Default
Number
