SECTION 6 - JLG CONTROL SYSTEM
3121607
– JLG Lift –
6-31
TILT:
9
1
2
3
4
5
5 DEGREES: Reduces the maximum speed of all boom functions to creep
when tilted more than 5 degrees and above elevation; also reduces drive
speed to creep.
4 DEGREES: Reduces the maximum speed of all boom functions to creep
when tilted more than 4 degrees and above elevation; also reduces drive
speed to creep.
3 DEGREES: Reduces the maximum speed of all boom functions to creep
when tilted more than 3 degrees and above elevation; also reduces drive
speed to creep.
4 DEGREES + CUT: Reduces the maximum speed of all boom functions to
creep when tilted more than 4 degrees and above elevation; also disallows
tower lift up, tower telescope out, drive, main telescope out and main lift up.
3 DEGREES + CUT: Reduces the maximum speed of all boom functions to
creep when tilted more than 3 degrees and above elevation; also disallows
tower lift up, tower telescope out, drive, main telescope out and main lift up.
1
Note: Any of the selections above will light the tilt lamp when a tilted condition occurs and will sound the platform alarm when
the machine is also above elevation.
JIB:
10
0
1
NO: No Jib installed.
YES: Jib installed which has up and down movements only.
0
STOUCH/SKY-
GUARD
:
12
0
1
2
3
NO: No soft touch or SkyGuard system installed.
SOFT TOUCH: Soft touch only installed.
SKYGUARD: SkyGuard only installed.
BOTH (CUTOUT) - Soft touch and SkyGuard installed.
0
GEN SET/WELDER:
13
0
1
NO: No generator installed.
BELT DRIVE: Belt driven setup
0
GEN SET CUTOUT:
14*
0
1
MOTION ENABLED: Motion enabled when generator is ON.
MOTION CUTOUT: Motion cutout in platform mode only.
0
* Only visible if Gen Set / Welder Menu selection is not 0.
H & T LIGHTS:
15
0
1
NO: No head and tail lights installed.
YES: Head and tail lights installed.
0
Table 6-5. Machine Configuration Programming Information
Configuration Digit
Number
Description
Default
Number
