Page 51
Form No. 20036 • G6-42A Owner/Operator Manual
NOMENCLATURE
Figure 17-1
17.0
MAINTENANCE
1
2
3
4
5
6
7
8
9
10
11
12
14
18
16
17
15
13
19
21
22
20
25
23
26
24
27
28
29
30
31
32
33
34
35
36
37
38
39
1.
FRONT AXLE
2.
TIE-DOWN LUGS
3.
SWAY CYLINDER
4.
HYDRAULIC
TANK & FILTER
5.
IMPLEMENT PUMP
6.
TRANSMISSION
OIL FILTER
7.
ENGINE COMPARTMENT
8.
MIRROR
9.
BATTERY
10.
TRANSMISSION
11.
ENGINE
12.
RADIATOR
13.
CONTROL VALVE
14.
HYDRAULIC OIL COOLER
15.
TRANSMISSION OIL
COOLER
16.
REAR AXLE
17.
PRIORITY VALVE
18.
AIR CLEANER
19.
STEERING CYLINDER
20.
REAR DRIVE SHAFT
21.
STEER SELECT VALVE
22.
FRONT DRIVE SHAFT
23.
STEERING CYLINDER
24.
BOOM HEAD
25.
THIRD BOOM SECTION
26.
SECOND BOOM SECTION
27.
FIRST BOOM SECTION
28.
CROWD CYLINDER
29.
OPERATORS CAB
30.
AIR CLEANER
31.
LIFT CYLINDER
32.
COMPENSATION
CYLINDER
33.
COUNTERWEIGHT
34.
TIE-DOWN LUGS
35.
REAR LUG NUTS
36.
FUEL TANK
37.
FRONT LUG NUTS
38.
ATTACHMENT TILT
CYLINDER
39.
QUICKSWITCH
9114-3282
STAY CLEAR OF PINCH POINT AREA
ANYTIME ENGINE IS RUNNING.
BEING IN PINCH POINT AREA COULD
CAUSE SERIOUS INJURY OR DEATH.
9114-3282
STAY CLEAR OF PINCH POINT AREA
ANYTIME ENGINE IS RUNNING.
BEING IN PINCH POINT AREA COULD
CAUSE SERIOUS INJURY OR DEATH.
DO NOT GO NEAR LEAKS
C
10814B
* High pressure oil easily punctures skin causing serious injury, gangrene or death.
* If injured, seek emergency medical help. Immediate surgery is required to remove oil.
* Do not use finger or skin to check for leaks.
* Lower load or relieve hydraulic pressure before loosening fittings.
9114-3283
NO RIDERS PERMITTED ON HANDLER.
OPERATOR ONLY IN MACHINE
WHILE RUNNING.
RIDERS COULD FALL OFF MACHINE
CAUSING SERIOUS INJURY OR DEATH.
9114-3286
DIESEL FUEL IS FLAMMABLE
EXTINGUISH ALL OPEN FLAME AND
SMOKING MATERIALS WHEN REFUELING
INJURY OR DEATH COULD RESULT
FROM FIRE.
** unknown **
** unknown **
2
NO
1
R
7733-3027
