Form No. 20036 • G6-42A Owner/Operator Manual
13.5
• Tilt carriage to left or right to align forks with load and engage load.
• Raise load slightly and then level carriage.
• Travel with load lowered to travel position 1.2m (4 feet) or less above
ground.
Boom Head-Mounted Winch
Capacity:
The boom head-mounted winch maximum load capacity is shown on the
standard carriage capacity chart. However, maximum capacity may be used
only in areas where it does not exceed capacities shown on standard
carriage/fork capacity chart (located on dashboard). Also note that maximum
winch capacity is less than carriage/fork maximum capacity. Capacity rating
is based on load being lifted and suspended vertically from the boom and
with no load on forks.
Observe the following Special Precautions:
• Never drag the load; lift vertically.
• Use tag line to guide and steady a suspended load. Tag lines must be
long enough to keep helpers clear of load and handler.
• Beware of wind. Wind can cause a suspended load to swing and cause
dangerous side loads - even with tag lines.
• Start, travel, turn and stop slowly to prevent load from swinging.
• Weight of all rigging (slings, etc.) must be included as part of load.
• Do not attempt to use handler frame-leveling to compensate for load
swing.
Attachment Tilt Controls:
Figure 13-6
The auxiliary control lever is used to
control the boom head-mounted winch.
Pull the lever back to raise winch load;
push the lever forward to lower winch
load.
Installation Procedure:
1. Install winch on boom head and connect hydraulic hoses at winch motor.
2. Position winch hook directly above balance point of load and secure using
appropriate rigging.
Operation:
• Attach tag lines to load and transport load to delivery site.
• While helpers guide load with tag lines, position load at delivery point.
WARNING !
Do not handle a load with Boom
Head-Mounted Winch attachment
until you study and understand
the “Boom Head-Mounted Winch
Capacity Chart” carefully. If your
handler does not have a “ Boom
Head-Mounted Winch Capacity
Chart,” ask your supervisor to
get one before using the
attachment.
WARNING !
PRECAUTIONS
• Maximum winch load
capacity is reduced from
normal carriage/fork load
rating.
• Always level handler before
lifting a load. See page 11.0.
• Travel with load and boom
lowered to travel position,
1.2m (4 feet) or less above
the ground.
• Always lower load to
rest before leaving handler.
WARNING !
AUXILIARY
CONTROL LEVER
LOWER
WINCH
LOAD
RAISE
WINCH
LOAD
A side load or a swinging
load could cause the
handler to tip over and/or
damage the boom.
