Page 269
SECTION 6 - HYDRAULIC
3121207
600S/660SJ/600SJ
269
FIGURE 6-1. HYDRAULIC DIAGRAM - DRIVE AND STEER (2WD/2WS)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
Note: 2WD Only Available on USA Built Machines
2792616
Ref
DRIVE AND STEER HYDRAULIC DIAGRAM - 2WD/2WS
5-O
1
2220362
1
Fitting, Tee
2
2220371
3
Fitting, Straight
3
2220373
5
Fitting, Straight
5
2220377
3
Fitting, Straight
6
2220415
2
Fitting, Straight
7
2220451
6
Fitting, Straight
8
2220473
4
Fitting, 90
9
2220504
2
Fitting, Tee
10
2220582
3
Fitting, Straight
11
2221170
1
Fitting, Tee
12
2220606
2
Fitting, Tee
14
2220307
2
Fitting, Plug
16
4641307
1
Valve, Check
18
2753925
2
Hose
19
2753924
1
Hose
24
2752592
2
Hose
25
2752910
1
Hose
26
2752478
1
Hose
27
2752632
1
Hose
28
2753397
2
Hose
29
2752475
1
Hose
30
2752611
1
Hose
31
2752928
1
Hose
32
2753929
2
Hose
33
2752929
1
Hose
34
2753969
2
Hose
35
2753967
2
Hose
36
2752341
1
Hose
37
2753435
1
Hose
38
Ref
Fitting, Straight Options:
38
2220371
1
Fitting, Straight (SN 0300087000 through 0300104455)
38
2220998
1
Fitting, Straight (SN 0300104456 through 0300171769)
