SECTION 4 - PLATFORM
3121207
600S/660SJ/600SJ
243
FIGURE 4-8. PLATFORM BUMPER PADDING INSTALLATIONS (OPTIONAL)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
0273542
Ref
PADDING INSTALLATION
A
1
0940092
4
Bumper, Pad (Corner)
2
0940094
9 ft/2.7m
Bumper, Pad (Square Tubing)
3
0940131
1
Bumper, Rail
4
0641516
2
Bolt 5/16in-18NC x 2in
5
4751500
2
Flatwasher 5/16in
6
3311505
2
Locknut 5/16in-18NC
7
0641813
4
Bolt 1/2in-13NC x 1-5/8in
8
3311805
4
Locknut 1/2in-13NC
9
4891800
4
Flatwasher 1/2in (Hardened)
10
4420068
30 ft/9.1m
Tape
1001110982
Ref
BUMPER INSTALLATION
D
102
4711400
10
Flatwasher1/4in Thin
103
1001110979
3
Bumper
104
1001110980
3
Clamp, Bumper
105
0100011
AR
Compound, Locking
106
0641418
10
Bolt 1/4in-20NC x 2-1/4in
107
0940159
2
Bumper
108
3300430
4
Nut, Acorn 1/4in-20NC
109
3311405
6
Locknut 1/4in-20NC
