SECTION 2 - TURNTABLE
3121207 600S/660SJ/600SJ 163
FIGURE 2-27. 2500W GENERATOR INSTALLATION - DEUTZ MACHINES (OPTIONAL)
ITEM PART NUMBER QTY DESCRIPTION REV
Ref GENERATOR INSTALLATIONS
Ref USA Built Machines: (SN 0300087000 through 0300139049)
0274082 Ref 110V/60Hz (Available on all Specs Except CE Spec) 3-C
0274090 Ref 110V/50Hz (Available on ANSI Export, Australian and CE
Specs) (SN 0300087000 through 0300133734) 1-A
0273045 Ref 110V/50Hz (Available on CE Spec - UK Only) (SN 0300087000
through 0300133734) 1-A
0273085 Ref 110V/50Hz (Available on CE Spec - Germany Only) (SN
0300087000 through 0300133734) 1-A
1001100308 Ref 110V/50Hz (Available on ANSI Export, Australian and CE
Specs) (SN 0300133734 through 0300139050) D
0274086 Ref 220V/50Hz (Available on ANSI Export, Australian and CE
Specs) (SN 0300087000 through 0300133734) 1-A
1001099868 Ref 220V/50Hz (Available on ANSI Export, Australian and CE
Specs) (SN 0300133734 through 0300139050) D
Ref USA Built Machines: (SN 0300139050 through 0300171769)
1001115405 Ref 110V/60Hz (Available on all Specs Except CE Spec) A
1001115410 Ref 110V/50Hz (Available on ANSI Export, Australian and CE
Specs) A
1001115409 Ref 220V/50Hz (Available on ANSI Export, Australian and CE
Specs) A
Ref China Built Machines: (SN B300000100 to Present)
1001115405 Ref 110V/60Hz (Available on all Specs Except CE Spec) A
1001115409 Ref 220V/50Hz (Available on ANSI Export, Australian and CE
Specs) A
Ref Note : See SPECIAL OPTIONS Section for Machines with
4000W Generator
1 3580158 1 Pulley
2 Ref Generator Component Options:
2 2460055 1 110V/60Hz Generator and Control Box Assembly (0274082
Installation)
2 2460057 1 110V/50Hz Generator and Control Box Assembly (0274090
Installation)
2 2460049 1 110V/50Hz Generator Only (1001099869, 1001115410,
0273045 & 0273085 Installations which Uses Junction Box or
Switch Box)
2 2460056 1 220V/50Hz Generator and Control Box Assembly (0274086
Installation)
2 1001100321 1 220V/50Hz Generator Only (1001100308 & 1001115409
Installation which Uses Junction Box)
2A 7012558 1 Generator Only - 110V/60Hz
2A 2460049 1 Generator Only - 110V/50Hz (was p/n 7019679 & 70000129)
2A 1001100321 1 Generator Only - 220V/50Hz (was p/n 7019679 & 70000128)
Ref Note: Replacement Generator come standard with p/n
3580134 pulley. This pulley may not be correct for all
applications. Refer to pulley options below.
2A Ref Armature with Slip Rings Options:
2A 7026199 1 Armature with Slip Rings - 110V/60Hz
2A 70000122 1 Armature with Slip Rings - 110V/50Hz
2A 70000123 1 Armature with Slip Rings - 220V/50Hz
2A 7012513 4 Cap, Brush Holder
2A 7020108 4 Brush
2A 7020109 4 Holder, Brush
