Page 141
SECTION 2 - TURNTABLE
3121207
600S/660SJ/600SJ
141
FIGURE 2-22. ENGINE TRAY JACK INSTALLATION (OPTIONAL)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
0255881
Ref
ENGINE TRAY JACK INSTALLATION
3-G
1
3537445
1
Bracket
2
3537446
2
Bracket
3
2840016
1
Hydraulic Jack Assembly Options:
F
3A
2840016
1
Burr Manufacturing Brand
3B
2840016
1
Hammerblow Corp and Cequent Brands
3C
Ref
Handle Options:
3C
7016374
1
Burr Manufacturing Brand
3C
7024598
1
Hammerblow Corp and Cequent Brands
3D
7016322
1
Wiper (Burr Manufacturing Brand Only)
4
0962051
2
Bushing, Flanged
5
3430816
1
Pin, Clevis
6
4891800
1
Flatwasher 1/2in Hardened
7
4711800
6
Flatwasher 1/2in Thin
8
3450404
1
Pin, Cotter 1/8in x 1in
9
0641609
4
Bolt 3/8in-16NC x 1-1/8in
10
3311605
4
Locknut 3/8in-16NC
11
4891600
4
Flatwasher 3/8in Hardened
12
0641818
4
Bolt 1/2in-13NC x 2-1/4in
13
3311805
4
Locknut 1/2in-13NC
15
1380147
1
Clip, Spring
22
3910608
2
Screw #6-32NC x 1in
23
3310601
2
Nut #6-32NC
24
4770600
2
Starwasher #6
