SECTION 5 - CYLINDER
3121207
600S/660SJ/600SJ
255
FIGURE 5-4. JIB LIFT CYLINDER ASSEMBLY - 600SJ & 660SJ
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1683609
Ref
JIB LIFT CYLINDER ASSEMBLY
K
1
1684089
1
Barrel
1A
0962336
2
Bushing
2
1683053
1
Head
3
3760368
1
Ring, Washer
4
3931516
8
Capscrew, Socket Head 5/16in-18NC x 1in
5
1684090
1
Rod
5A
0962336
2
Bushing
6
4640509
2
Cartridge, Valve
6
2900792
2
Seal Kit - 4640509 Valve
8
2220883
2
Plug, O-Ring #4
9
2220885
1
Plug, O-Ring #6
10
3480210
1
Piston
11
0961893
1
Bushing, Tapered
12
4100100
1
Spacer, Tube
14
2901303
2
Seal
15
2901303
2
Ring, Lock
16
2901303
2
O-Ring
17
2901303
2
Ring, Back-Up
18
2901303
1
O-Ring
19
2901303
1
Ring, Back-Up
20
2901303
1
Seal, Rod
21
2901303
1
Wiper
22
2901303
1
Ring, Wear
23
0100011
AR
Compound, Locking
24
0100038
AR
Primer, Locking
26
0630534
3
Bolt #10-24NC x 1in
100
2901303
1
Seal Kit (Includes Items 14-22)
