Page 227
SECTION 4 - PLATFORM
3121207
600S/660SJ/600SJ
227
FIGURE 4-4. PLATFORM CONSOLE ASSEMBLY (USA BUILT MACHINES AND CHINA BUILT
MACHINES) (SN 0300138729 through 0300171769, SN B300000100 to Present)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
Note: Machines “Without UGM” are ALL USA Built Machines.
Ref
Note: Platform Console Module is different based on the
Ground Control Module (i.e. with UGM or without UGM). For
Ground Module identification, see Revision Log Page A.
Ref
CONSOLE BOX AND FOOTSWITCH ASSEMBLIES
1001108790
Ref
Without UGM
C
1001114449
Ref
With UGM (USA Built Machines) (use p/n 1001145895)
B-F
1001114449
Ref
With UGM (China Built Machines) (Use p/n 1001145895)
B-F
1
0100009
AR
Sealant
2
0100035
AR
Compound, Locking
3
0100048
AR
Grease, Dielectric
4
0100081
AR
Loctite #454
5
0140011
1
Alarm
7
0630464
2
Screw, Button Head #10-24NC x 1/2in
8
0641404
4
Bolt 1/4in-20NC x 1/2in
9
0641414
4
Bolt 1/4in-20NC x 1 3/4in
10
0721006
2
Screw #10-24NC x 3/4in
11
0861537
1
Box, Console (See Items 201-206 for Breakdown)
12
0902751
4
Bracket, Module Support
13
Ref
Controller Assembly (Lift and Swing) Options (See
CONTROLLER ASSEMBLY (LIFT AND SWING) for Breakdown)
13
1600317
1
Controller USA Built Machine (Use p/n 1001129555) (SN
0300087000 through 0300146163)
13
1600317
1
Controller China Built Machines (Use p/n 1001129555) (SN
B300000100 through B300000271)
13
1001118417
1
Controller USA Built Machines (Use p/n 100112955) (SN
0300146164 through 0300171769)
13
1001118417
1
Controller China Built Machines (Use p/n 1001129555) (SN
B300000272 to Present)
14
Ref
Controller Assembly (Drive and Steer) Options (See
CONTROLLERLER ASSEMBLY (DRIVE AND STEER) for
Breakdown):
14
1600318
1
Controller USA Built Machines (Use p/n 1001118416) (SN
0300087000 through 0300146163)
14
1600318
1
Controller China Built Machines (Use p/n 1001118416) (SN
B300000100 through B300000271)
14
1001118416
1
Controller USA Built Machines (SN 0300146164 through
0300171769)
14
1001118416
1
Controller China Built Machines (SN B300000272 to Present)
15
Ref
Controller, Module Options (Re-calibration Required when
Replaced):
15
1600375
1
Without UGM
15
1001106355
1
With UGM
16
1670829
1
Bezel
17
1671037
1
Cover (Use p/n 1001110434)
18
1702565
1
Decal (Drive and Steer)
19
1702566
1
Decal (Lift and Swing)
20
1702567
1
Decal (Function Speed)
21
1704260
1
Decal (EMS)
22
1705132
1
Decal (ADE)
23
2560136
1
Handle, Knob
