Page 31: Platform component description -3

SECTION 3 - MACHINE OPERATION

LIFTPOD by JLG

1001070465

www.liftpod.com

3-3

Platform Configuration

Figure 3-3. Base frame component description - FS60

Rotating castor

Adjustable Foot

Self Retracting Swivel Castor

Adjustable Foot

Carriage Rests

Mast Stump

Level Bubble

Retracting Castor
Release Lever

FRONT

(travel stops)

Step Plate

Rotating castor

Figure 3-4. Platform component description

Platform Swing Gates

Mounting Pin

Authorized Lanyard Anchorage Point

Platform Locator

Platform Latch

Mounting Pin

Powerpack Mounts

Powerpack Latch Mount

Manual Storage
Compartment (other side)
