SECTION 9 - RECOMMENDED SERVICE PARTS STOCK
84
15BD/19BD
3121155
FIGURE 9-1. 15BD STANDARD PARTS
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Note
Ref
Note: The following list will service fleets of machines (built to
current production per date on the front cover) with emergency
repair parts which can be installed in the field. Parts from the
list should be replaced when inventory is depleted to keep
service parts stock supplied. For further information, contact
your JLG dealer or the JLG Industries Parts Department
Ref
STANDARD PARTS
7020078
1
Switch, Push Button (Red)
4360467
1
Switch, Key
2860030
1
Key Replacement
7026165
1
Filler
70000643
1
Coil
70001025
1
Cap/Breather
3740049
1
Relay
3740093
1
Relay (115V)
3740094
1
Relay
4360161
2
Breaker, Circuit - 20 Amp (115V)
4360070
2
Breaker, Circuit - 15 Amp (230V)
2400006
2
Fuse 5-Amp
7020088
1
Switch, Push Button (White)
7020089
1
Switch, Push Button (Green)
3990010
2
Diode 6 Amp
7023993
1
Coil
