Page 21
SECTION 2 - CONTROLS
3121155
15BD/19BD
21
FIGURE 2-3. MOTOR/PUMP ASSEMBLY (Including SN 0130005748)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
USAGE CHART:
3600467
1
Pump/Motor Assembly - 15BD with 120VAC, 60Hz Motor
without AC Outlet (See Previous Figure) (Excluding SN
0130005748)
3600453
1
Pump/Motor Assembly - 15BD with 120VAC, 60Hz Motor
(Shown in This Figure)
3600453
1
Pump/Motor Assembly - 19BD with 120VAC, 60Hz Motor
(Shown in This Figure)
3600453
1
Pump/Motor Assembly - All Machines with 120VAC, 50-60Hz
Motor & AC Outlet (Shown in This Figure)
3600453
1
Pump/Motor Assembly - All Machines with 220VAC, 50-60Hz
Motor (Shown in This Figure)
3600453
Ref
MOTOR/PUMP ASSEMBLY
B
1
70000641
1
Adapter, Motor/Pump/Tank (Includes Items 17 & 18)
2
70000642
1
Cartridge
3
70000643
1
Coil
5
70000644
1
Pump
6
3931420
4
Screw 1/4in-20NC x 1- 1/4in
7
70000645
1
Tube, Suction
8
7026165
1
Filter
9
70000646
1
Tube, Return
10
70000647
1
Plate, Motor Adapter
11
70000648
4
Screw 1/4in-20NC x 3/4in
12
70000649
1
Shaft, Intermediate
13
70000650
1
Motor
14
70000651
1
Reservoir
15
7026160
1
Plug
16
7026335
1
Clamp
17
70000641
1
Valve, Relief (Note: Part of Item 1)
17
70000641
1
Screw
17
70000641
1
Nut
17
70000641
1
Seal
17
70000641
1
Spring
17
70000641
1
Ball
18
70000641
1
Valve, Check (Note: Part of Item 1)
18
70000641
1
Plug
18
70000641
1
Spring
18
70000641
1
Poppet
18
70000641
1
Ball
