SECTION 2 - CONTROLS
3121155
15BD/19BD
19
FIGURE 2-2. MOTOR/PUMP ASSEMBLY (ALL MACHINES) (Excluding SN 0130005748)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
USAGE CHART:
3600467
Ref
Pump/Motor Assembly - 15BD with 120VAC, 60Hz Motor
without AC Outlet (Shown in This Figure) (Excluding SN
0130005748)
3600453
Ref
Pump/Motor Assembly - 15BD with 120VAC, 60Hz Motor (See
Next Figure) (Including SN 0130005748)
3600453
Ref
Pump/Motor Assembly - 19BD with 120VAC, 60Hz Motor (See
Next Figure)
3600453
Ref
Pump/Motor Assembly - All Machines with 120VAC, 50-60Hz
Motor & AC Outlet (See Next Figure)
3600453
Ref
Pump/Motor Assembly - All Machines with 220VAC, 50-60Hz
Motor (See Next Figure)
3600467
Ref
MOTOR/PUMP ASSEMBLY
C
1
70000641
1
Base Assembly (Includes Items 14-18)
2
70001021
1
Pump (Includes Item 3)
3
70001020
4
Screw 1/4in-20NC x 2-3/4in
4
70001042
1
Tube, Suction
5
7026165
1
Filter
6
70001044
1
Tube, Return
7
70001045
1
Motor (Includes Item 19 and Motor Bolts)
8
70000642
1
Cartridge
9
70000643
1
Coil
10
70000651
1
Reservoir
11
70001025
1
Plug
12
7026335
1
Clamp
13
70001027
1
Decal - Fill Line
14
70000641
1
Valve, Relief (Note: Part of Item 1)
14
70000641
1
Screw
14
70000641
1
Nut
14
70000641
1
Seal
14
70000641
1
Spring
14
70000641
1
Ball
15
70000641
1
Valve, Check (Note: Part of Item 1)
15
70000641
1
Plug
15
70000641
1
Spring
15
70000641
1
Poppet
15
70000641
1
Ball
16
70003612
1
O-Ring (1/2in x 5/8in x 1/16in)
17
70003613
1
O-Ring (3-5/8in x 3-7/8in x 1/8in)
18
7026330
1
Seal
19
70002215
1
Bearing
