Page 16
SECTION 2 - CONTROLS
16
15BD/19BD
3121155
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
18
3911024
1
Screw #10-24NC x 1-1/2in (Used on 120 VAC, 50-60Hz Only)
Ref
PUMP/MOTOR AND JUNCTION BOX INSTALLATION
B
0275939
Ref
All Machines with Gullwing or Right Side Entry Platforms
(Excluding SN 0130005748)
A
1001126224
Ref
All Machines with Left Side Entry Platforms (Not Shown)
(Excluding SN 0130005748)
A
Ref
Note: Right/Left Side Gate Entry determined by operator's
position when facing push button controls.
101
0100011
AR
Compound, Locking
102
0641404
4
Bolt 1/4in-20NC x 1/2in
103
0791609
4
Bolt 3/8in-16NC x 1-1/8in
106
3311608
4
Nut, Flanged 3/8in-16NC
107
4061024
1
Shield, Pump Cover
110
4711400
4
Flatwasher 1/4in Thin
0275697
Ref
HOURMETER INSTALLATION (OPTIONAL)
C
203
2420172
1
Hourmeter
205
4922935
1
Harness, Hourmeter (Not Shown)
A
