SECTION 6 - HYDRAULIC
3121155 15BD/19BD 67
FIGURE 6-1. HYDRAULIC DIAGRAM
ITEM PART NUMBER QTY DESCRIPTION REV
Ref Note: Right/Left Side Gate Entry determined by operator's
position when facing push button controls.
Ref HYDRAULIC DIAGRAM OPTIONS:
0275939 Ref All Machines with Gullwing or Right Side Entry Platforms
(Excluding SN 0130005748) A
10011126224 Ref All Machines with Left Side Entry Platforms (Not Shown)
(Excluding SN 0130005748) A
2915246 Ref Hydraulic Diagram (Including SN 0130005748 ) 2
4 2220473 2 Fitting
5 Ref Fitting Options:
5 2220473 2 Fitting All Machines (Excluding SN 0130005748)
5 2220603 2 Fitting (Including SN 0130005748)
8 Ref Tube, Return Options:
8 1001100544 1 Tube, Return All Machines (Excluding SN 0130005748)
8 4569478 1 Tube, Return (Including SN 0130005748)
9 Ref Tube, Extend Options:
9 1001100545 1 Tube, Extend All Machines (Excluding SN 0130005748)
9 4569479 1 Tube, Extend (Including SN 0130005748)
