JLG 19BD Parts Manual User Manual
Page 45
SECTION 3 - MAST
3121155
15BD/19BD
45
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
212
1260349
2
Chain Kit (Includes Qty 1 of #201-203, 206 & 210 and Qty
71in/1.8m of #204)
E
1260357
Ref
CHAIN/CLEVIS ASSEMBLY - #444 CHAIN
E
301
0100062
AR
Compound, Locking (use p/n 0100019)
302
0561149
2
Block
303
0561408
2
Block Options
304
item 312
AR
Chain
305
3422338
2
Pin, Clevis
306
3422346
2
Pin, Groove
307
3450355
2
Pin, Groove
308
3450304
2
Pin, Cotter
309
3571101
1
Plate, Clevis
310
4300111
2
Stud
311
4711500
2
Flatwasher 5/16in Thin
312
1260349
2
Chain Kit (Includes Qty 1 of #301-303, 306 & 310 and Qty
71in/1.8m of #304)
E
1001128991
Ref
HEIGHT LIMITER INSTALLATION
A
401
0100011
AR
Compound, Locking
402
0641407
2
Bolt 1/4in-20NC x 7/8in
403
0903671
1
Bracket, Mounting
404
3311405
2
Locknut 1/4in-20NC
405
3820024
2
Rivet
406
3900205
2
Screw #10-24NC x 5/8in
407
4360515
1
Switch, Proximity
408
4240033
AR
Tie-Strap (Not Shown)
409
4711400
4
Flatwasher 1/4in Thin
410
4751000
2
Flatwasher #10 Regular
411
1001132981
1
Plate
412
4460267
2
Pin, Male
413
4460424
1
Connector - 2 Position
