SECTION 4 - PLATFORM
3121155 15BD/19BD 53
FIGURE 4-3. PLATFORM (26IN/66CM X 25IN/63.5CM) WITH SWING GATE
ITEM PART NUMBER QTY DESCRIPTION REV
Ref Note: Right/Left Side Gate Entry determined by operator's
position when facing push button controls.
Ref PLATFORM INSTALLATION
1001141303 Ref Platform with Rear Gate Entry A
1001134102 Ref Platform with Left Side Gate Entry (Not Shown) A
1001141301 Ref Platform with Right Side Gate Entry (Not Shown) A
1 0641622 6 Bolt 3/8in-16NC x 2-3/4in
2 0860520 1 Box, Manual Storage
3 1703681 2 Decal - JLG
4 1704277 2 Decal - Lanyard
5 3311605 6 Locknut, 3/8in-16NC
6 3820032 4 Rivet
7 4711600 12 Flatwasher 3/8in Thin
8 1001133771 1 Platform Assembly Options (See Items 101-112 for Breakdown)
1001133771 Ref PLATFORM ASSEMBLY A
101 0100011 AR Compound, Locking
102 0641416 8 Bolt 1/4in-20NC x 2in
103 2080040 16 Blind Fastener
104 2080043 8 Rivnut
105 1001133770 1 Platform Weldment (use p/n 1001133771)
106 2600294 4 Hinge, Self Closing
107 3520028 2 Plug, Hole
108 3520072 8 Cap-Plug
109 4220309 4 Stop
110 4071095 AR Shim, Hinge
111 1001139325 1 Gate, Right
112 1001132793 1 Gate, Left
