7-6 3120626
SECTION 7 ELECTRICAL S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
PLATFORM BUMPER PROXIMITY SWITCHES
ELECTRICL DIAGRAM OPTIONS: Ref.
1282190 Chain Attach Bumper Proximity Switch (Soft Ref. B
Touch System) (Electrical Diagram)
4360057 Switch, Limit 1
4360274 Switch, Push-Button (Override) 1
3740049 Relay 2
4932075 Welded-on Bumper Proximity Switch Electrical
Diagram Ref. B
3740045 Relay 1
4360274 Switch, Push Button (Override) 1
PLATFORM WORKLIGHT WIRING DIAGRAM Ref.
OPTIONS:
2900068 Machines Built Prior to November 1992 Ref. F
0253987 Machines Built November 1992 to Present Ref. C
0251610 Machines with 48V U/L Options Ref. —
2920095 Worklight 2
4931887 POWER TOOL WIRING DIAGRAM Ref. —
4932025 POWER TOOL WIRING DIAGRAM Ref. —
PROXIMITY WIRING DIAGRAM Ref.
4932075 Standard Machines Ref. B
4932661 U/L Machines Ref. A
0250698 RECEPTACLE BOX WIRING DIAGRAM - 120VAC Ref. —
(440 VAC MACHINES)
STANDARD WIRING DIAGRAMS - DEUTZ: Ref.
4932056 Prior to January 1993 Ref. G
4932613* January 1993 to Present Ref. D
4921265 Engine and Valve Harness 1
3990010 Diode - 6 Amp 5
3730095 Resistor 7.5 Ohm 10 Watt 1
1060016 Cable, Electrical - 16/3 20 Ft.
STANDARD WIRING DIAGRAMS - FORD: Ref.
4931926 Prior to March 1990 Ref. B
4932071 March 1990 to January 1993 Ref. D
4932614 January 1993 to October 1994 Ref. D
4932755* October 1994 to Present Ref. B
4921167 Engine and Valve Harness (Prior to March 1990) 1
4921282 Engine and Valve Harness (March 1990 to
Present) 1
1060016 Cable, Electrical - 16/3 20 Ft.
3990010 Diode - 6 Amp 6
3730095 Resistor 7.5 Ohm 10 Watt 1
FIGURE 7-1.ELECTRICAL DIAGRAM LIST
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
