3120626 4-21
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
S
SECTION 4 PLATFORM
FIGURE 4-6. CONSOLE BOX ASSEMBLY - PQ CONTROLLERS AND VICKERS VALVES
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
CONSOLE BOX ASSEMBLY - PQ CONTROLLERS & Ref.
VICKERS VALVES
0250203 Gas, Diesel & Dual Fuel Machines Built Prior To
April 1990 Ref. 8
0250607 All Electric Machines Built To Present Ref. E
0254438 Receptacle Installation - 110V Ref. 3
1 Lid Options: 1
3251894 Lid (Prior to May 1994)
3252392 Lid (May 1994 to Present)
2 0751006 Screw, Pan Head #10-24NC x 3/4” 18
3 4740120 Washer, Nylon 18
4 3300177 Nut, Tinnerman 18
5 4420038 Tape, Insulation 3 1/4 Ft.
0100001 Adhesive A/R
6 0860538 Box, Control Includes Items 10-12) 1
7 3311505 Nut 5/16”-18NC A/R
8 4751500 Flatwasher 5/16” 8
9 4320002 Stud, Mounting A/R
0641508 Bolt 5/16”-18NC x 1" A/R
10 2940052 Latch 2
11 2600132 Hinge (Top to Bottom) 1
12 2600105 Hinge (Access Door) 1
13 1600094 Controller, PQ (Note: Refer to JLG Manual 3120351
for more information) 4
70003737 Electrical Assembly 4
14 4360274 Switch, Push Button (Horn) 1
3790015 O-Ring 1
15 4360199 Switch, Toggle (Ignition) 1
3790012 O-Ring 1
4360141 Guard, Switch 1
16 4360274 Switch, Push Button (Start) (Gas, Diesel & Dual Fuel 1
Only)
3790015 O-Ring 1
3520026 Plug, Hole (Electric) 1
17 3520026 Plug, Hole 1
18 4360202 Switch, Toggle (Tower Tele) 1
4060229 Shield 1
3790012 O-Ring 1
19 4360202 Switch, Toggle (Rotate) 1
4060229 Shield 1
3790012 O-Ring 1
20 4360202 Switch, Toggle (Level) 1
4060229 Shield 1
3790012 O-Ring 1
21 2920015 Lamp (Chassis Out of Level) 1
