2-131
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
SECTION 2 TURNTABLE
FIGURE 2-37. GROUND CONTROL BOX INSTALLATON (GAS/DIESEL MACHINES WITH
HYDRAULIC BOOM LIMIT SWITCHES BUILT MAY 1988 TO MARCH 1990 & ELECTRIC MACHINES
WITH HYDRAULIC BOOM LIMIT SWITCHES BUILT MAY 1988 TO PRESENT)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
GROUND CONTROL BOX ASSEMBLY (STANDARD Ref.
PARTS)
0239023 Kohler Gas with Stepper Valves Ref. D
0239060 Kohler Gas with Vickers Valves Ref. C
0239780 Ford Gas with Vickers Valve Ref. A
0239351 Kubota Diesel with Stepper Valves Ref. B
0239352 Kubota Diesel with Vickers Valves Ref. B
0239024 Electric Machines with Stepper Valves Built May
1988 to April 1990 Ref. D
0250992 Electric Machines with Stepper Valves Built April
1990 to Present Ref. C
0250610 Electric Machines with Vickers Valves Built May
1988 to Present Ref. B
1 to 6 Not Used
7 4842906 Control Box Weldment 1
8 Not Used
9 0750806 Screw, Self Tapping #8 x 3/4” 6
10 4760800 Lockwasher #8 6
11 3300177 Fastener, Self Retaining 6
12 4360200 Switch, Toggle (Auxiliary Power) 1
13 Not Used
14 4360003 Switch, Master 1
2860002 Key, Replacement 1
15 4360202 Switch, Toggle (Main Lift) 1
16 4360202 Switch, Toggle (Main Telescope) 1
17 2420009 Hourmeter 1
18 4360202 Switch, Toggle (Swing) 1
19 4360202 Switch, Toggle (Tower Lift) 1
20 4360202 Switch, Toggle (Tower Telescope) 1
21 Not Used
22 4360201 Switch, Toggle (Select Switch) 1
23 3740049 Relay A/R
3311001 Nut #10-24NC 1
4761000 Lockwasher #10 1
24 4360216 Breaker, Circuit - 30 Amp 1
3311001 Nut #10-24NC 1
4761000 Lockwasher #10 1
25 4360232 Breaker, Circuit - 15 Amp 1
3311001 Nut #10-24NC 1
4761000 Lockwasher #10 1
26 4460051 Connector 3
0960238 Bushing 3
3300048 Locknut, Conduit 3/4” 3
27 4460071 Connector 1
0960238 Bushing 1
3300048 Locknut, Conduit 3/4” 1
