JLG 45HA ANSI Parts Manual User Manual
Page 207
2-143
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
SECTION 2 TURNTABLE
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
HOODS INSTALLATION
Ref.
0239708
Ford Gas, Dual Fuel & Straight LP Only
Ref.
C
0238721
Kohler Gas
Ref.
C
0238686
Kohler Dual Fuel
Ref.
C
0239543
Kubota Diesel
Ref.
C
0238687
Electric Machines Prior to December 1989
Ref.
D
0250191
Electric Machine December 1989 to November 1991
Ref.
C
0252480
Electric Machines November 1991 to Present
Ref.
A
Note: Replacement Decals Must Be Ordered Sep-
arately - See Section 8.
Ref.
1 to 2
Not Used
3
4842885
Door Weldment
1
4
2940057
Latch, Sliding
1
5
0641406
Bolt 1/4”-20NC x 3/4”
4
6
4711400
Flatwasher 1/4” Narrow
A/R
7
3311405
Locknut 1/4”-20NC
A/R
8
Not Used
9
4300073
Stud (Welded on Part)
2
10
4751500
Flatwasher 5/16”
2
11
3311505
Locknut 5/16”-18NC
2
12
4070410
Shim 1/16”-16.6mm Thickness
A/R
13
4070411
Shim 1/8”-3.2mm Thickness
A/R
14
4070412
Shim 3/16”-4.8mm Thickness
A/R
15
3532202
Plate, Cover
2
16
3941406
Screw, Self-Tapping 1/4” x 3/4”
A/R
17
4761400
Lockwasher 1/4”
A/R
18
0641408
Bolt 1/4”-20NC x 1"
A/R
19
4751400
Flatwasher 1/4”
A/R
20
4300031
Stud (Welded on Part)
A/R
21
3300151
Nut, Acorn 1/4”-20NC
A/R
22
2940050
Latch
1
23
3820019
Rivet
A/R
24
2940048
Latch
A/R
25
3532260
Plate, Cover
1
26
3820012
Rivet
2
27 to 50
Not Used
51
Hood (Right Side) Options:
1
4843265
Ford Gas, Dual Fuel & Straight LP Only
4842964
Kohler Gas & Dual Fuel
4843209
Kubota Diesel
4842964
Electric Machines
52
Ventilator Options:
1
4843267
Ford Gas, Dual Fuel & Straight LP Only
4842961
Kohler Gas & Dual Fuel
4843208
Kubota Diesel
4842961
Electric Machines
