2-132
SECTION 2 TURNTABLE S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
28 3640555 Rail, Mounting 2
3910608 Screw, Round Head #6-32NC x 1/2” 2
4750600 Flatwasher #6 2
3310601 Nut #6-32NC 2
29 4460299 Stop, Terminal 4
30 3740058 Relay (Lift, Swing and Tele) A/R
4120013 Socket, Relay A/R
3740063 Spring, Relay A/R
31 4460298 Strip, Terminal 12
4460301 Strip, Terminal Marking 1
32 4460309 Bar, Terminal Connecting 1
4460305 Screw, Block 3
4460306 Washer, Block 3
4460307 Sleeve, Block 3
33 4460300 Barrier, Terminal 2
34 1320044 Clamp 1
35 1320130 Clamp 1
36 to 50 Not Used
51 Panel, Front Options: 1
3251840 Gas and Diesel Machines
3251841 Electric Machines Prior to May 1994
3252381 Electric Machines May 1994 to Present
52 Component Options: 1
4360274 Switch, Push Button (Choke) (Kohler Gas)
3520026 Plug (Ford Gas)
4360274 Switch, Push Button (Glow Plug) (Kubota Diesel)
3251872 Nameplate - Glow Plug (Kubota Diesel)
4360274 Switch, Push Button (Run) (Electric Machines)
53 Component Options: 1
4360201 Switch, Toggle (With Dual Fuel)
3520028 Plug (Without Dual Fuel)
54 Board, PC - Remote Speed Set A/R
Not Required Kohler, Kubota & Electric Machines 0
4360228 Ford Machines 1
3310601 Nut #6-32NC 2
4760600 Lockwasher #6 2
4564088 Tube, Spacer 2
GROUND CONTROL BOX INSTALLATION Ref.
With Stepper Valves: Ref.
0238558 Gas Machines with Stepper Valves Ref.
0239026 Gas Machines with Stepper Valves Ref.
0239353 Diesel Machines with Stepper Valves Ref.
0238560 Electric Machines with Stepper Valves Ref.
0250991 Electric Machines with Stepper Valves Ref.
With Vickers Valves: Ref.
0259061 Gas Machines with Vickers Valves Ref.
0259783 Gas Machines with Vickers Valves Ref.
FIGURE 2-37. GROUND CONTROL BOX INSTALLATON (GAS/DIESEL MACHINES WITH
HYDRAULIC BOOM LIMIT SWITCHES BUILT MAY 1988 TO MARCH 1990 & ELECTRIC MACHINES
WITH HYDRAULIC BOOM LIMIT SWITCHES BUILT MAY 1988 TO PRESENT) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
