JLG 45HA ANSI Parts Manual User Manual
Page 179
2-115
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
SECTION 2 TURNTABLE
FIGURE 2-32. DOUBLE BATTERY PACKAGE AND INVERTER INSTALLATIONS (ELECTRIC
MACHINE OPTIONS)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
0239421
DOUBLE BATTERY PACKAGE
Ref.
C
1
Battery Options:
16
0400067
Battery (Wet) (Standard)
0400113
Battery (Dry) (Optional)
2
3300029
Wingnut 3/8”-16NC
6
3
4740273
Washer, Special
6
4
0236768
Rod, Holddown
6
5
3980003
Seat, Masonite
16
6
0840016
Boot, Terminal
32
7
1060084
Cable
14
8
1060197
Cable, Battery
2
9
1060105
Cable Assembly - Battery
1
10
2820025
Guard, Cable
1
11
4843150
Try
2
12
3420158
Hairpin (Top Tray Only)
2
13
3421594
Pin, Flathead
1
14
3420157
Pin, Quick Release
1
15
2540014
Grommet, Flex Trim
4 ft.
16
3532913
Plate, Side (Right Hand)
1
17
3532914
Plate, Side (Left Hand)
1
18
3311601
Nut 3/8”-16NC
8
19
4761600
Lockwasher 3/8”
8
4300034
Stud (Welded on Parts)
6
20
4751600
Flatwasher 3/8”
2
21
0641612
Bolt 3/8”-16NC x 1 1/2”
2
22
3200285
Slide, Box
1 pr.
23
0640413
Screw, Button Head
16
0100011
Loctite
A/R
24
4843198
Box Weldment
1
0239403
INVERTOR INSTALLATION
Ref.
A
101
2460017
Invertor
1
102
0641403
Bolt 1/4”-20NC x 3/8”
4
103
4761400
Lockwasher 1/4”
4
0560816
Block, Mounting (Welded on Part) (Not Shown)
4
104
1670484
Cover Weldment
1
105
3311401
Nut 1/4”-20NC
4
106
4761400
Lockwasher 1/4”
4
4300031
Stud (Welded on Part) (Not Shown)
4
107
2940048
Latch
2
3820019
Rivet
2
