2-47
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
SECTION 2 TURNTABLE
FIGURE 2-16. FORD ENGINE INSTALLATION - WITH ELECTRONIC IGNITION (PRIOR TO MARCH
1990)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
FORD ENGINE INSTALLATION - WITH ELECTRONIC Ref.
IGNITION (PRIOR TO MARCH 1990)
FORD ENGINE ASSEMBLY (STANDARD PARTS) Ref.
1 2000093 Engine - Ford VSG-411 1
2 Not Used
3 2720341 Hose, Air Cleaner Outlet 1
4 0641509 Bolt 5/16”-18NC x 1 1/8” 2
5 4761500 Lockwasher 5/16” 2
6 to 8 Not Used
9 Pump Assembly Options: 1
3600152 Pump Assembly (Vickers) 1
2900660 Shaft Seal Kit (Vickers) 1
3600200 Pump Assembly (Barnes) (1 each of fittings p/n’s 1
2220376 & 2210014 are required when replacing
Vickers pump with Barnes pump) (See Figure 2-23
for Breakdown)
10 0641812 Bolt 1/2”-13NC x 1 1/2” 2
11 4761800 Lockwasher 1/2” 3
12 2180623 Fitting, Tee 1
13 4843272 Exhaust Weldment 1
14 1320014 Clamp, Hose 4
15 4751800 Flatwasher 1/2” 2
16 3311801 Nut 1/2”-13NC 2
17 2720264 Hose, Radiator - Upper 1
18 0701014 Bolt 10mm x 30mm 5
19 4761700 Lockwasher 7/16” 5
20 2420024 Sender, Temperature 1
21 4843287 Plate, Mounting - Governor 1
22 0641408 Bolt 1/4”-20NC x 1" 13
23 4761400 Lockwasher 1/4” 15
24 3311401 Nut 1/4”-20NC 11
25 4751400 Flatwasher 1/4” 4
26 2500004 Governor, Electronic (Precision Governor) 1
27 2420033 Sender, Oil Pressure 1
28 2220273 Fitting, Reducer 1
29 Not Used
30 4751500 Flatwasher 5/16” 2
31 2180360 Fitting, Tee 2
32 4360037 Switch, Pressure 1
33 2200101 Plug, Pipe 1
34 3840906 Rod, Throttle Control 1
35 3321001 Nut #10-32NF 2
36 0310003 Balljoint 1
37 0310004 Balljoint 1
38 0901385 Bracket 1
39 4564367 Tube, Dipstick 1
