SECTION 3 - MACHINE CONTROLS, INDICATORS AND OPERATION
3-8 – JLG Lift – 3121135
3.6 GROUND CONTROL STATION -
PROGRAMMING
General
The DVL/DVSP machine Ground Control Station allows
on-board programming of various component and control
function personality settings.
Programming may be required under circumstances such
as:
• Optional equipment has been added to the machine in
the field and a function must be enabled before opera-
tion.
• Customizing the machine to fit a specific application,
such as changing the LCD display language.
Programming Levels
There is one (1) password protected programming level
available to the Operator:
• Level-3: Operator’s Settings -
Level-3 Password: 33271
Operator Programming Mode
In the Operator Level Programming Mode the following
items are shown on the main menu (See Table 3-4 for Set-
ting Range and Default Factory Setting):
• Tilt Sensor
• Program
• Tilt Sensor
Allows viewing current tilt sensor individual X and Y
direction degree reading.
• Program
Allows programming of the items shown in Table 3-4,
the following is a brief explanation of each program-
ming item.
NOTE: There are two production modules available at this
time, one for North/South American and European
languages, and one for Asian languages. All pro-
grammable items between these modules are identi-
cal with the exception of language selection.
• Back To Main - When selected, will return to main
level menu.
• Set Language - Selects the language that text on
the LCD screen will be displayed.
• Set Sleep Time - Allows setting the length of time
the machine will remain powered up without control
input before powering itself down.
• Set Polarity of Keypad Code - Turns on or off the
Programmable Security Lock switch circuit, if
equipped.
• Enable Detection of Horn Open Circuit - Enables
horn electrical circuit to be turned on (YES) or off
(NO) if machine is equipped with a horn.
Table 3-4. DVL/DVSP Ground Control Station - Level 3 - Programmable Settings and Factory Presets.
Level-3: Operator Programmable Settings On LCD Display: YES =
!
HIGH =
↑
NO =
✕
LOW =
↓
LEVEL PROGRAMMABLE ITEM
FACTORY
PRESET
SETTING RANGE
3 Back to Main — Return to Main Menu
3 Set Language
NOTE: There are two production modules available at this
time, one for North/South American and European
Languages, and one for Asian Languages.
1 1 - English 6 - Italian
2 - German 7 - Swedish
3 - Dutch 8 - Brazilian Portuguese
4 - French 9 - Finnish
5 - Spanish
2 1 - English 3 - Japanese
2 - Chinese
3 Set Sleep Time 5 MINS 0 - 60 MINS
3 Set Polarity of the Keypad Code LOW HIGH/LOW
3 Enable Detection of Horn Open Circuit NO (a) YES/NO
3 Enable Detection of Beacon Open Circuit NO (a) YES/NO
3 Forward Alarm Disable NO YES/NO
3 OSS Diagnostics NO YES/NO
Notes: (a) DVSP Models this feature is standard equipment and preset to YES at factory.
