SECTION 5 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE
5-2 – JLG Lift – 3121135
Electrical Specifications
Platform Data
Machine Component Weights
Serial Number Locations
For machine identification, a serial number plate is affixed to the machine. The plate is located on the back of the mast, just
above the mast support bracket.
SPECIFICATION 15DVL 20DVL 15DVSP 20DVSP
System Voltage: 24 Volts DC
Battery Specifications: Battery Type: AGM (VRLA) (Sealed)
Voltage: 12 Volts DC
Amp Hour (AH) Rating: 100 Amp Hr. @ 20 Hr.
Battery Charger (DC Models) Input: 120/240 Volts AC - 50/60 Hz - Voltage Selectable
Output: 24 volt, 20 Amp Output - with 2 Amp Finish
SPECIFICATION 15DVL 20DVL 15DVSP 20DVSP
Occupants: (Persons allowed in Platform) 1
Maximum Work Load (Capacity): Standard: 500 lb.
(230 kg)
350 lb.
(160 kg)
— —
Stockpicker:
— —
500 lb.
(230 kg)
400 lb.
(180 kg)
Extendible: 500 lb.
(230 kg)
350 lb.
(160 kg)
500 lb.
(230 kg)
350 lb.
(160 kg)
Molded: 500 lb.
(230 kg)
350 lb.
(160 kg)
500 lb.
(230 kg)
350 lb.
(160 kg)
Platform Height - Mast Fully Extended -
(Ground to Platform Floor): 15 ft.
(4.57 m)
19.5 ft.
(5.94 m)
15 ft.
(4.57 m)
19.5 ft.
(5.94 m)
Platform Cycle Performance: Lift Up: 20 sec. 22.5 sec. 20 sec. 22.5 sec.
(in seconds) (w/max. rated load) Lift Down: 15 - 21 sec. 21 - 26 sec. 15 - 21 sec. 21 - 26 sec.
SPECIFICATION 15DVL 20DVL 15DVSP 20DVSP
Platform Weight : Standard Platform: 55 lb. (25 kg)
(Quick-Change Platforms) Molded Platform: 70 lb. (32 kg)
Battery: (per battery) 65.7 lb. (29.8 Kg)
