2-16 1930ES, 2030ES 2630ES, 2646ES & 3246ES 3121246
SECTION 2 GROUND COMPONENTS
Ref. GROUND CONTROL BOX INSTALLATION
0272810 Ref. ANSI &ANSI Export & UL Specs F
0273966 Ref. ANSI Export & Japanese Spec C
0273443 Ref. Australian Spec D
0272811 Ref. CE Spec F
101 0100011 A/R Compound, Locking (USA Built Machines S/N 0200117805 to
S/N 0200120587 & Belgium Built Machines S/N 1200001367 to
S/N 1200001698)
102 to 103 Not Used
104 0700615 3 Bolt M6 x 35mm
0272878 Ref. ANTI-VANDELISM PACKAGE INSTALLATION (NOT SHOWN) A
1671124 1 Cover, Lockable Ground Control Box
FIGURE 2-4. GROUND CONTROL ASSEMBLY & INSTALLATION (USA BUILT MACHINES S/N
0200117805 TO S/N 0200135154 & BELGIUM BUILT MACHINES S/N 1200001367 TO S/N
1200004293) (CONTINUED)
ITEM # PART NUMBER QTY. DESCRIPTION REV.
