2-8 1930ES, 2030ES 2630ES, 2646ES & 3246ES 3121246
SECTION 2 GROUND COMPONENTS
17A 4 Latch Options (2 Per Cover):
2940174 Standard
2940175 Locking
7027863 Key
17B 4071102 4 Shim, Latch (2 Per Cover)
17C 1671203 1 Cover, Battery (USA Built Machines S/N 0200130607 to
S/N 0200135154 & Belgium Built Machines S/N
1200003527 to S/N 1200004293)
17D 1705754 1 Decal - JLG (USA Built Machines S/N 0200130607 to S/
N 0200135154 & Belgium Built Machines S/N
1200003527 to S/N 1200004293)
17E 1706350 2 Decal - Cover (USA Built Machines S/N 0200130607 to
S/N 0200135154 & Belgium Built Machines S/N
1200003527 to S/N 1200004293)
18 Not Used
19 4240172 4 Strap, Battery (UL Spec)
Ref. TRAY ASSEMBLY OPTIONS:
0273698 Ref. USA & Belgium E
0861678 Ref. UL Spec C
101 Purchase Item 16 1 Tray, Battery
102 3290605 2 Locknut
103 3340975 2 Pad, Wear (Note: Wear Pad not available separately from Tray
Assembly on some applications.)
104 Stop, Battery Box Options:
Ref. NOTE: Requires (2) 3820032 Rivet & (1) 4811600 Washer
Use 4220252 1 LH (was p/n 4220208)
Use 4220253 1 RH (was p/n 4220208)
105 3820032 A/R Rivet (USA Built Machines S/N 0200130607 to
S/N 0200135154 & Belgium Built Machines S/N 1200003527 to
S/N 1200004293 - Not Shown)
106 4811600 A/R Washer (USA Built Machines S/N 0200130607 to
S/N 0200135154 & Belgium Built Machines S/N 1200003527 to
S/N 1200004293 - Not Shown)
FIGURE 2-2. BATTERIES AND COVERS INSTALLATION (USA BUILT MACHINES S/N
0200128413 TO S/N 0200135154 & BELGIUM BUILT MACHINES S/N 1200002974 TO S/N
1200004293) (CONTINUED)
ITEM # PART NUMBER QTY. DESCRIPTION REV.
