RackSwitch G8000 Application Guide
Chapter 5: Spanning Tree „ 89 BMD00041, November 2008
Configuring Multiple Spanning Tree Groups
This configuration shows how to configure MSTP Groups on the switch, as shown
in
Figure 5-3 .
1. Configure port membership and define the Spanning Tree groups for VLAN 1.
Enable tagging on uplink ports that share VLANs. Port 51 and port 52 connect to the Enter-
prise Routing switches.
Add server ports 1 and 2 to VLAN 1. Add uplink ports 51 and 52 to VLAN 1.
2. Configure Multiple Spanning Tree Protocol.
Configure the MSTP region name, set the Spanning-tree mode to mst, and configure the
version.
RS G8000 (config)# interface port 51
RS G8000 (config-if)# tagging
RS G8000 (config-if)# exit
RS G8000 (config)# interface port 52
RS G8000 (config-if)# tagging
RS G8000 (config-if)# exit
RS G8000 (config)# vlan 1
RS G8000 (config-vlan)# enable
RS G8000 (config-vlan)# member 3
RS G8000 (config-vlan)# member 4
RS G8000 (config-vlan)# member 5
RS G8000 (config-vlan)# member 51
RS G8000 (config-vlan)# member 52
RS G8000 (config-vlan)# stg 1
RS G8000 (config-vlan)# exit
RS G8000 (config)# spanning-tree mstp name MyRegion
RS G8000 (config)# spanning-tree mode mst
RS G8000 (config)# spanning-tree mstp version 100
