RackSwitch G8000 Application Guide
126
Chapter 8: Basic IP Routing
BMD00041, November 2008
5.
Assign a VLAN to each IP interface.
Now that the ports are separated into VLANs, the VLANs are assigned to the appropriate IP
interface for each subnet. From
, the settings are made as follows:
6.
Configure the default gateway to the routers’ addresses.
The default gateway allows the switch to send outbound traffic to the router:
7.
Enable IP routing.
8.
Verify the configuration.
Examine the resulting information. If any settings are incorrect, make the appropriate changes.
RS G8000 (config)# interface ip 1
(Select IP interface 1)
RS G8000 (config-ip-if)# ip address 205.21.17.3
RS G8000 (config-ip-if)# ipvlan 1
(Add VLAN 1)
RS G8000 (config-ip-if)# enable
RS G8000 (config-vlan)# exit
RS G8000 (config)# interface ip 2
(Select IP interface 2)
RS G8000 (config-ip-if)# ip address 100.20.10.1
RS G8000 (config-ip-if)# ipvlan 2
(Add VLAN 2)
RS G8000 (config-ip-if)# enable
RS G8000 (config-ip-if)# exit
RS G8000 (config)# interface ip 3
(Select IP interface 3)
RS G8000 (config-ip-if)# ip address 131.15.15.1
RS G8000 (config-ip-if)# ipvlan 3
(Add VLAN 3)
RS G8000 (config-ip-if)# enable
RS G8000 (config-ip-if)# exit
RS G8000 (config)# interface ip 4
(Select IP interface 4)
RS G8000 (config-ip-if)# ip address 206.30.15.1
RS G8000 (config-ip-if)# ipvlan 4
(Add VLAN 4)
RS G8000 (config-ip-if)# enable
RS G8000 (config-ip-if)# exit
RS G8000 (config)# ip gateway address 205.21.17.1
RS G8000 (config)# ip gateway enable
RS G8000 (config)# ip routing
RS G8000 (config)# show vlan
RS G8000 (config)# show interface information
RS G8000 (config)# show interface ip
