Aries Automotive 209014-2 User Manual
Page 8
SIDEBAR
2014-2015 NISSAN ROGUE
EXCLUDES 2014 “SELECT” MODEL
Page 7 of 7 5/28/14 (DP)
Passenger Side Installation Pictured
Front
Front
Front
(Fig 16) Passenger side front Bracket pictured
(Fig 17) Passenger side center Bracket pictured
(Fig 18) Passenger side center Bracket pictured.
Trim cover to clear Bracket after all Brackets
have been lined up and installed. Marks
indicating area to cut are for example only
Complete Installation
(2) 6mm x 25mm Hex Bolts
(4) 6mm Flat Washer
(2) 6mm Lock Washer
(2) 6mm Hex Nuts
