Aries Automotive 209014-2 User Manual
Page 7
SIDEBAR
2014-2015 NISSAN ROGUE
EXCLUDES 2014 “SELECT” MODEL
Page 6 of 7 5/28/14 (DP)
Passenger Side Installation Pictured
Front
Front
Front
Front
Fig 12A
(Fig 12B) Insert fully installed
Fig 13
(Fig 14) Passenger front Bracket
location marked before drilling
8mm Threaded Insert
8mm x 25mm Hex Bolt
8mm Lock Washer
8mm Flat Washer
(Fig 15) Passenger center Bracket
location marked before drilling
