Aries Automotive 209014-2 User Manual
Page 5
SIDEBAR
2014-2015 NISSAN ROGUE
EXCLUDES 2014 “SELECT” MODEL
Page 4 of 7 5/28/14 (DP)
Passenger Side Installation Pictured
(Fig 5) Passenger side rear mounting location
Rear
Rear
Rear
(Fig 6A) 8mm Bolt Plate
(Fig 6B) 8mm Bolt Plate with tab
(Fig 6C) Passenger rear mounting
location pictured from below. Scrape
off excess sealant from mounting
location before installing rear Bracket
(Fig 7) Passenger rear Bracket
8mm Bolt Plate
with tab
8mm Bolt Plate
