3042F 1997-98 Ford F Series/Expedition Installation
Parts List
1 – Front Aries Bar
2 – Frame Brackets
6 – 7/16 x 1 ¼” Hex Bolts 6 – 7/16 hex nuts
12 – 7/16 Flat washers
Installations of Bottom Frame Bracket
Remove tow hooks from the front of the vehicle.
Using the bolts that held the tow hooks in place attach the mounting bracket ad the
diagram below. (using two bolts per hook) Do not fasten bolts too tight. Allow your self
to adjust for the alignment.
Installation of the Front Bar
Line up the three holes on the lower portion of the front bar with three holes on the frame
mounting brackets (outer edge). Using the 7/16” hex bolts, nuts and washers, fasten the
front bar to the mounting brackets, leaving it loose for adjustment.
Once the front bar is attached to the mounting brackets, align until you’re satisfied with
the fit and balance and tighten all fasteners.
NOTE: it is advisable to re-check all fasteners for tightness after one week.
Mount to frame in this direction
Passenger Driver
