Aries Automotive 209014-2 User Manual
Page 6
SIDEBAR
2014-2015 NISSAN ROGUE
EXCLUDES 2014 “SELECT” MODEL
Page 5 of 7 5/28/14 (DP)
Passenger Side Installation Pictured
8mm x 25mm Hex Bolt
8mm Lock Washer
8mm Flat Washer
(2) 8mm Flat Washers
(2) 8mm Lock Washers
(2) 8mm Hex Nuts
(Fig 8) Passenger side rear Bracket
pictured from below vehicle
Rear
Front
Fig 9
(Fig 10) Locate the 6th hole along
the bottom of the frame rail
Fig 11
Clamps
Front
4
5
8mm x 25mm Hex Bolt
8mm Flat Washer
8mm Threaded Insert
Tool
