Diagram of auto level and variable height – Snorkel XT24SD-sn000001+ User Manual
Page 18
1/31/2008
- 22 -
Diagram of Auto Level and Variable Height
Variable
Height
Raise and
Lower
Controls
Push to
Enable
Button
Platform and
Ground Key
Level
Machine
Button
Emergency
Lowering
Emergency
Stop
Retract Legs
and Override
Button
Outrigger
Lights
Down Light
Alarm
Light
Platform
Overload
Low
Voltage
